SL8410 降压恒流驱动IC 5A电流 60W功率

详情描述：

General Description
    The SL8410 is an average current mode control LED driver IC operating in a constant off-timemode.SL8410 does not produce a peak-to-average error,and therefore greatly improves accuracy,line and load regulation of the LED current without any need for loop compensation or high-sidecurrent sensing.The output LEDcurrent accuracy is ?2%.
    The SL8410 can be powered from an 8.0-100V supply.PWM & Linear dimming input is provided that accepts an external control TTL compatible signal.The output current can be programmed by an internal 277mV reference.

Features
Fast Average Current Control
Internal 8 to 100V Linear Regulator
Linear and PWM Dimming Capability
Output Short Circuit Protection With Skip Mode
Requires Few External Components for Operation

Applications
DC/DC LED Driver Applications
LED Street Lighting
Back Lighting of Flat Panel Displays
General Purpose Constant Current Source
Signage and Decorative LED Lighting
Chargers
